With front and rear fender,
Mozo suspension fork,
LED light front and back,
heavy luggage rack
Specification details
| Electric System | Main Components | ||
| Motor | 36V 350W brushless | Frame | 6061 aluminium alloy; 36 month warranty |
| 24 month warranty | Tyres | 20"*4.0 KENDA Fat tire | |
| Battery | 36V10Ah Lithium battery | Rim | Alloy Aluminum |
| Samsung Cells | Front fork | Mozo suspension fork aluminium | |
| 18 month warranty | Front brake | Tektro hydraulic brake | |
| PAS | Pedal Assisted System | Rear brake | Tektro hydraulic brake |
| Controller | Smart controller; 18 month warranty | Spokes | Stainless steel |
| Charger | 100~240V, 50-60Hz | Derailleur | Shimano 7 speed |
| 12 month warranty | Stem | Alloy Aluminum,foldable | |
| Performance | Brake lever | Tektro brake lever | |
| Max speed | 28km/h | Chain | KMC Rust resistant chain |
| Range | More than 55kms/full charge | Chain wheel | Steel 48T |
| Max load | 120kgs | Saddle | Soft comfortable |
| Net weight | 23kgs | Display | LED display |
| Gross weight | 28kgs with carton box | Handle Bar | Alloy Aluminum |
| Container load | 108pcs/20FT, 270pcs/40HQ | Packing size | 1450*260*680mm |
Detail
7 Speed Shimano derailleur
LCD player
7 Layer Double Wall Carton. Retail packing available. We will produce labels for you,
with your company logo.
BEITE workshop
Strong packing for sample delivery
After-sales service
Payment
1.Sample: 100% payment. Delivery 15-35 days after recieved payment
2.Orders: 30% deposite, balance aginst see the copy of bill of lading(B/L)
3.We will offer free aftersale parts for your orders.
This is our standard specification bike, we can adjust the specification according to what you like.
